Technical Parameters

Voltage: AC100~240V, 50~60Hz

Power Consumption: 600W

Light source: 380W high brightness lamp ( Osram 371/Phoenix 380 optional)

Lifespan: about 4000 hours

Color temperature: 7800K

Signal Control: DMX512, auto

DMX Channel: 18CH

Scanning Angle: X: 540°, Y: 270°. 16bit/8bit control, dual-sensor positioning, with automatic error-correction function.

Color Wheel: 14 fixed color + white, capable of achieving multiple effects such as rainbow, semi-color, full-color, and flowing water.

Gobo Wheel: 17 fixed gobo + white, capable of achieving multiple effects such as pattern jitter and flowing water.

Prism 1: 8-facet prism.

Prism 2: 8+16+24-facet prism.

Two prisms can be superimposed and can rotate independently in both directions.

Main Lens: High-precision and high temperature resistant glass lens.

Other Lens: 1 frost len + 1 seven-color len.

Beam angle: 2° (without prism).

Focusing: 0~100% linear.

Dimming: 0 - 100% linear.

Strobe: 1~14Hz mechanical strobe.

Appearance: High temperature resistant ABS plastic + molded alloy material.

IP Rated: IP20.

Dimensions: 270mm×380mm×620mm (L×W×H).

Net weight: 19.5kg.
